Atlantic 600 Horizontal Windlass 600W Kit w/ Nylon Double Braided Rope/Chain and Swivel

Five Oceans

Product image 1Atlantic 600 Horizontal Windlass 600W Kit w/ Nylon Double Braided Rope/Chain and Swivel
Product image 2Atlantic 600 Horizontal Windlass 600W Kit w/ Nylon Double Braided Rope/Chain and Swivel
Product image 3Atlantic 600 Horizontal Windlass 600W Kit w/ Nylon Double Braided Rope/Chain and Swivel
Product image 4Atlantic 600 Horizontal Windlass 600W Kit w/ Nylon Double Braided Rope/Chain and Swivel
Product image 5Atlantic 600 Horizontal Windlass 600W Kit w/ Nylon Double Braided Rope/Chain and Swivel
Product image 6Atlantic 600 Horizontal Windlass 600W Kit w/ Nylon Double Braided Rope/Chain and Swivel
Product image 7Atlantic 600 Horizontal Windlass 600W Kit w/ Nylon Double Braided Rope/Chain and Swivel
Product image 8Atlantic 600 Horizontal Windlass 600W Kit w/ Nylon Double Braided Rope/Chain and Swivel

Regular price $982.49 Free Shipping

PRODUCT # 3930-C2

GOOD TO KNOW
Safe & Secure Checkout
24/7 Customer Support
Same Day Dispatch (Order by 2pm)
The Five Oceans Atlantic 600 Horizontal Windlass Kit has a stylish look, 100% stainless-steel design which sits elegantly on the deck.
Not to mention, it's fitted with a heavy-duty lever for easy installation.
Noteworthy is the importance of the gypsy creating the perfect contact between rope and chain. It includes an impact-resistant motor cover, solenoid and standard switches which fit perfectly on the cockpit or bow of the vessel. This Atlantic series windlass is ideal for your average cruiser, the bigtime fisherman, those made for speed or the calm sailor.
This Kit comes with one Nylon Double Braided Windlass Rope 1/2"x150FT w/ Galvanized 1/4"x15FT HT G4 Chain, Prespliced and one Stainless Steel Swivel.

SPECIFICATIONS:

WINDLASS:

Installation Details:
Note for decks that are not flat, a suitable mounting pad may be required to take up camber or sheer. Decks made of a thin, foam or balsa laminate construction, will require reinforcement in order to spread the loads that will be applied to the deck while the windlass is in use. The standard (1/4") threaded mounting studs supplied suit deck and packing thickness of up to 50 mm (2"). These are adequate for most installations.

Features:
DIY - ready mounting template for convenient on-deck installation
Powerful motor for fast and secure anchor retrieval at the push of a button
Includes a dual set of switches for either the bow or the console.
Suitable for boats up to 35 feet in length
Backed by a 1-year warranty

Model: Atlantic 600
Motor: 600W
Maximum Pull: 1200 lbs (540 kg)
Voltage: 12 Volts
Current draw(A): 33 Amps - Max current draw(A): 55Amps
Circuit Breaker: 60 Amps
Boat Length: 16 FT to 32 FT
Rope Type: Three(3) strand nylon is the recommended rope.
Chain Size: 1/4" HT G4
Rope Size: 1/2" (12 mm)
Rode Types - Rope/Chain.
Retrieval Speed: 70 Feet per minute
Drop Speed: 115 Feet per minute
Max. working load (kgs/Ib): 180/400
Max. power pull (kgs/Ib): 540/1200
Material: 316 Stainless Steel
Type: Horizontal

ROPE/CHAIN

Rope 1/2"x150FT w/ Galvanized 1/4"x15FT HT G4 Chain
Diameter: Rope 1/2" (12 mm) / Chain 1/4" (6 mm)
Material: Nylon Double Braid Anchor Rope / HT G4 Galvanized Chain (Hot dip galvanized to minimize corrosion)
Working Load: Rope 1100 lb (500 kg) I Chain 1800 lb (825 kg)
Recommend Boat Length: up to 40 Feet (12 m)
Type: Pre-Spliced Rope and Chain Rode

PRODUCT NUMBER: 3930-C2

DOWNLOAD PRODUCT MANUAL(S): product manual for five oceans sku product.sku   product manual for five oceans sku product.sku

PRODUCT WARRANTY

Open tab

One (1) Year Warranty

We take enjoyment in the products we make and guarantee the buyer that all Five Oceans products are ready to handle the extreme conditions of the open sea or terrain. However, we also know things can happen that's why we've got you covered for a year.

Click Here to read the warranty document
